Epcos (B41252A6159M000) Electrolytic Capacitor, Snap-in, 15000µF

Product Description

The Epcos B41252A6159M000 is a large-capacity aluminum electrolytic capacitor rated at 15000 µF, 50 V, with a ±20% tolerance and snap-in mounting for secure PCB integration. Built with a fully insulated aluminum case, standard snap-in solder pins (6.0 ±1mm), and PVC insulation sleeve with minus pole marking, it's a standard general-purpose grade capacitor designed for reliable performance. It's rated for 2000 hours of service life at 105°C and offers a ripple current capability of 5.24A, making it well-suited for power supplies, frequency converters, and other industrial applications requiring high-capacity energy storage and filtering.

Quick Spec Sheet

• Capacitance: 15000 µF
• Voltage rating: 50 V DC
• Tolerance: ±20%
• Mounting type: Snap-In (6.0 ±1mm pins)
• Polarity: Polar
• Rated life: 2000 hours at 105°C
• Ripple current: 5.24 A
• Diameter: 35mm
• Height: 50mm
• Lead spacing: 10mm
• Operating temperature: -40°C to +105°C
• Case: Fully insulated aluminum, PVC sleeve
• Series: B41252
