Epcos (B82477G4682M000) Power Inductor (SMD), 6.8µH, 6.5A, Shielded

Product Description

The Epcos B82477G4682M000 is a shielded SMD power inductor rated at 6.8 µH, built with a magnetically shielded ferrite core and enamel copper wire winding soldered directly to leadfree tinned terminals for reliable, low-noise performance. It offers a robust current rating of 6.5 A, making it well-suited for demanding power conversion applications. Its shielded construction helps minimize electromagnetic interference, and it's designed for use in filtering of supply voltages, DC-DC converters, and automotive electronics, where compact size and high-current handling are essential.

Quick Spec Sheet

• Inductance: 6.8 µH
• Inductance tolerance: ±20%
• Rated current: 6.5 A
• Construction: Shielded, wirewound, ferrite core
• Terminals: Enamel copper wire, soldered, leadfree tinned
• Case size: 12.8mm x 12.8mm
• Mounting type: SMD (Surface Mount)
• Product range: B82477-G4 Series
• Typical applications: Supply voltage filtering, DC-DC converters, automotive electronics
