Epcos (CLF6045NIT-3R3N-D) Power Inductor (SMD) 3.3µH 3.7A Shielded

Product Description

The Epcos (TDK) CLF6045NIT-3R3N-D is a shielded SMD power inductor rated at 3.3 µH, built with a wirewound ferrite core construction for reliable, low-noise performance. It offers a current rating of 3.7 A with a low DC resistance of 0.025Ω, delivering efficient performance at a 100kHz operating frequency. Its shielded design helps minimize electromagnetic interference, and it's automotive-grade (AEC-Q200 qualified), making it well-suited for automotive electronics, DC/DC converters, and other applications demanding high reliability in compact spaces.

Quick Spec Sheet

• Inductance: 3.3 µH
• Inductance tolerance: ±30%
• Rated current: 3.7 A
• DC resistance (max): 0.025 Ω
• Operating frequency: 100 kHz
• Construction: Shielded, wirewound, ferrite core
• Case size: 6.3mm x 6mm x 4.5mm
• Mounting type: SMD (Surface Mount)
• Qualification: AEC-Q200 (Automotive)
• Product range: CLF6045NI-D Series
