EPCOS (B41689A5458Q001) Electrolytic Capacitor 4500µF 25V (TDK)

Product Description

The EPCOS B41689A5458Q001 is an axial-leaded aluminum electrolytic star capacitor rated at 4500 µF, 25 V, designed specifically for automotive electronics applications requiring exceptional durability. It offers very high ripple current capability (rated at 10A) and a long useful life of 10,000 hours at temperatures up to 125°C, with a low ESR of 0.013Ω for excellent efficiency under sustained high-current loads. Its axial-lead, soldering construction makes it well-suited for reliable, long-term integration into automotive power systems and other demanding high-temperature environments.

Quick Spec Sheet

• Capacitance: 4500 µF
• Voltage rating: 25 V DC
• Tolerance: -10%, +30%
• Terminal type: Axial Leaded (soldering)
• Polarity: Polar
• ESR: 0.013 Ω
• Ripple current: 10 A
• Diameter: 21mm
• Length: 49mm
• Operating temperature: -55°C to +125°C
• Rated life: 10,000 hours at 125°C
• Applications: Automotive electronics
• Series: B41689
