EPCOS (B41858C7477M000) Electrolytic Capacitor 470µF 35V (TDK)

Product Description

The EPCOS/TDK B41858C7477M000 is a radial-leaded aluminum electrolytic capacitor rated at 470 µF, 35 V, with a ±20% tolerance, designed for reliable performance in demanding electronic circuits. It's AEC-Q200 qualified for automotive use and rated for 5,000 hours of service life at 105°C, with a low ESR of 0.073Ω and a ripple current rating of 1.2A. Its compact 10mm x 20mm radial can package with 5mm lead spacing makes it well-suited for automotive ECUs, power supply filtering, and other space-constrained circuit designs requiring long-term reliability.

Quick Spec Sheet

• Capacitance: 470 µF
• Voltage rating: 35 V DC
• Tolerance: ±20%
• Terminal type: Radial Leaded
• Polarity: Polar
• ESR: 0.073 Ω (@ 10kHz)
• Ripple current: 1.2 A
• Diameter: 10mm
• Height: 20mm
• Lead spacing: 5mm
• Operating temperature: -55°C to +105°C
• Rated life: 5,000 hours at 105°C
• Qualification: AEC-Q200 (Automotive)
• Series: B41858
