Epcos (B32355C4305J015) Motor Run Capacitor Metallized PP Can 3µF (TDK)

Product Description

The Epcos/TDK B32355C4305J015 is a MotorCap S3 motor run capacitor built from metallized polypropylene (PP) film, housed in a compact plastic can filled with dry resin for durability. Rated at 3 µF and 400 VAC, it conforms to the highest safety class S3 as specified in IEC 60252-1 and is IEC 60335-1 compatible for household and similar electrical appliance applications. The capacitor features self-healing properties, high insulation resistance, and a low dissipation factor, with wire lead terminals for straightforward installation. Its high continuous operating temperature rating of up to 100°C makes it well-suited for demanding motor run applications in fans, pumps, and general sine-wave motor circuits.

Quick Spec Sheet

• Capacitance: 3 µF
• Tolerance: ±5%
• Voltage rating: 400 VAC (50/60 Hz)
• Dielectric material: Metallized Polypropylene (PP)
• Case style: Can, plastic with resin fill
• Terminals: Wire leads (2 x 100mm cables)
• Diameter: 25mm
• Height: 60.5mm
• Operating temperature: -25°C to +100°C
• Safety class: S3 (IEC 60252-1)
• dv/dt rating: 10 V/µs
• Series: B32355C – MotorCap S3 Compact
• Typical applications: Motor run capacitor for fans, pumps, general sine-wave motor circuits
