Epcos (B43724A9688M000) Electrolytic Capacitor 6800µF 400V (TDK)

Product Description

The Epcos (TDK) B43724A9688M000 is a large-can aluminum electrolytic capacitor rated at 6800 µF, 400 V, with a ±20% tolerance and screw terminal construction for secure, high-current connections. Built for demanding industrial power applications, it's rated for 12,000 hours of service life at 85°C, offering a long operational lifespan under sustained load. With a low ESR for improved efficiency and a rugged aluminum housing, it's well-suited for use in high-power inverters, welding equipment, industrial power supplies, and other applications requiring high-voltage energy storage and filtering.

Quick Spec Sheet

• Capacitance: 6800 µF
• Voltage rating: 400 V DC
• Tolerance: ±20%
• Terminal type: Screw
• Rated life: 12,000 hours at 85°C
• ESR: 0.017 Ω
• Diameter: 76.9mm
• Height: 130.7mm
• Lead spacing: 31.7mm
• Operating temperature: -40°C to +85°C
• Series: B43724
