Omron (D3V-16G-1C25) Microswitch, Miniature, Pin Plunger, SPDT

Microswitch, Miniature, Pin Plunger, SPDT, Quick Connect, 16 A, 250 V Product Information Microswitch Type: Miniature Microswitch Actuator: Pin Plunger Contact Configuration: SPDT Switch Terminals: Quick Connect Contact Current Max: 16A Contact Voltage DC Nom: 250V Product Range: D3V Contact Voltage AC Nom: 250V Operating Force Max: 1.96N Product Overview The D3V-16G-1C25 is a single-pole double-throw (SPDT) miniature Basic Switch with quick-connect terminals, a pin plunger actuator and 0.5mm (G gap) contact gap. Silver alloy contact 100MR at 500VDC Minimum insulation resistance 30mR Maximum contact resistance IP40 Protection rating Applications Industrial
